SPECIFICATIONS

Assist System: Torque Sensor(The instrument can be set with torque or cadence.)

Battery: 48V 15Ah (720Wh), LG 21700 Cells, with BMS

Bike Weight: 34.5 kg(76.1 lbs)

Brake Type: Tektro Hydraulic, Dual-Piston

Brand Name: ENGWE

Cassette: 8-Speed, 13T-28T

Certification: UL 2849 Certified by Tuv Rheinland

Chain: C8R8 Anti-Rust, 116 Links

Chainring: 52T

Charger: 54.6V 8A Output

Crank: 170mm

Disc Rotor: 203mm Front & Rear Drivetrain

Display: 3.5" LCD Color Display, ENGWE-Designed, Mid-Position, with Bluetooth

Fold: Yes

Fork: Hydraulic, Adjustable Lockout, Aluminum & Iron

Frame Material: 6061 Aluminum Alloy, Internal Battery, Step-Through Design

Frame Style: Compact, Full Suspension

Front Light: 30 Lux with Integrated E-Horn

Handlebars: 680mm Width

IOT: ENGWE IOT Module with GPS, 4G & Bluetooth

Max Load Capacity: 150kg (330 lbs)

Max Mileage: Max range of the 60 Miles at PAS mode 1

Max Speed: <25km/h,28MPH (The actual speed will vary due to rider weight and road conditions)

Max Torque: 90Nm

Model Number: L20 3.0

Motor: 750W Rated, 1500W Peak Hub Motor

Origin: Mainland China

Pedal Assist: 5 Levels

Pedals: Boron Steel, Non-Foldable

Power Source: Lithium battery

Power Supply: Lithium battery

Puncture Protection: 3mm Anti-Puncture Layer

Range per Power: > 60 km

Rear Derailleur: Shimano Tourney RD-M310, 8-Speed

Rear Light: Automatically brightens When Braking or Shaking

Rear Suspension: 30mm Travel Wheel Set

Ride Height: 5'0" - 6'2" (155cm - 190cm)

Saddle: ENGWE Soft Saddle

Seat Clamp: Quick-Release

Seat Post: 10-Level Adjustable

Shifter: Shimano SL-M315-8R

Stem: Foldable

Terrain: Tarmac Roads & Bicycle Routes Gravel-Paved Paths Sandy Beaches & Grass Country Roads & Paved Trails

Tires: 20 x 3.0 Urban Hybrid Tires

Voltage: 48V

Waterproof Ratings: IPX4

Wheel Size: 20 x 3.0

Wheels: 20-inch, 12-gauge Spokes, 36-hole, Double-Wall Aluminum, Black

Meet the ENGWE L20 3.0 — the first e-bike in its price range to combine full suspension comfort and smart IoT anti-theft protection, redefining what a commuter e-bike can be. Engineered for your daily life, its full suspension system absorbs every bump in the road to turn rough commutes into smooth rides, while the GPS-powered IoT anti-theft module lets you track, lock, and monitor your bike in real time, so you never stress about leaving it unattended. Whether you’re navigating city streets or exploring trails, the L20 3.0 delivers the comfort, safety, and peace of mind you deserve — all in a foldable, UL-certified package.

Package Contents:

✔ 1× L20 3.0 Full Suspension Electric Bike

✔ 1×48V 15Ah LG Lithium-Ion Battery

✔ 1×54.6V 8A Fast Charger

✔ 1×Accessory Kit (Tools & Essentials)

🔹 Key Highlights – L20 3.0

✔ Full Suspension System (Front Hydraulic + Rear 30mm Travel)

✔ Smart IOT GPS Anti-Theft System (ENGWE IOT Module)

✔ 750W Rated / 1500W Peak Motor (90Nm Torque)

✔ 48V 15Ah LG 21700 Battery (720Wh, 60 Miles Max Range)

✔ UL 2849 Certified & Tektro Hydraulic Disc Brakes

✔ 20"×3.0" Urban Hybrid Tires with Anti-Puncture Layer
